The post PerFET™ 80V および 100V パワーMOSFET first appeared on Taiwan Semiconductor.

]]>

タイワン・セミコンダクター社は、高周波スイッチングに最適化された次世代PerFET™ 80Vおよび100VパワーMOSFETを発表します。これらのデバイスは、通信およびサーバー電源における同期整流、ならびに太陽光インバータ、電動工具、DC-DCブリックコンバータ、電源アダプタなどの産業用アプリケーションに最適です。

小型PDFN56Uパッケージに収められたPerFET™ 80Vおよび100V MOSFETは、基板と端子のはんだ接合部の信頼性を向上させ、自動光学検査 (AOI) の精度を高めるウェッタブルフランク端子構造を特長としています。製品ポートフォリオには18種類の製品展開があり、標準ゲートドライブ (10V) とロジックレベルゲートドライブ (5V) の両方のオプションを提供することで、設計者はアプリケーションに最適なソリューションを柔軟に選択できます。

図1:PDFN56U および PDFN56U Dual パッケージ

Key Features

  • 信頼性 (AEC-Q101要件に適合)
  • クラス最高のFOM (RDS(on) ) * Qg)
  • 低い導通損失のための最適化されたRDS(on)
  • スイッチング損失低減のための低ゲート電荷
  • 175°Cのジャンクション温度 (TJ)
  • ウェッタブルフランクによるAOI精度の向上

Applications

  • 48V車載アプリケーション
  • SMPS、サーバーおよび通信電源
  • DC/DCコンバータ
  • BLDCモータードライバー
  • E-Fuse

Product Portfolio

Part NumberPackageVDS (V)RDS(on) @ 10V Max. (mΩ)VGS(TH) (V)ID (A)Qg (nC) @ 10V
TSM048NH10LCRPDFN56U1004.81.4 - 2.210047
TSM048NH10CR4.82.4 - 3.610035
TSM075NH10LCR7.51.4 - 2.210036
TSM075NH10CR7.52.4 - 3.610022
TSM100NH10LCR101.4 - 2.27225
TSM100NH10CR102.4 - 3.67220
TSM170NH10LCR171.4 - 2.25017
TSM170NH10CR172.4 - 3.65011
TSM240NH10LCR241.4 - 2.2349.3
TSM240NH10CR242.4 - 3.6348.1
TSM250NH10LDCRPDFN56U Dual251.4 - 2.23110
TSM250NH10DCR252.4 - 3.6318.4
TSM058NH08LCRPDFN56U805.81.4 - 2.210035
TSM063NH08CR6.32.4 - 3.610027
TSM130NH08LCR131.4 - 2.25417
TSM145NH08CR14.52.4 - 3.65213
TSM210NH08LDCRPDFN56U Dual211.4 - 2.23311
TSM230NH08DCR232.4 - 3.6319.1
Facebook
LinkedIn
Email

The post PerFET™ 80V および 100V パワーMOSFET first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/perfet-80v-and-100v-power-mosfets/feed/ 0
MPS構造採用 1200V ワイドバンドギャップ SiC ショットキーダイオード:高周波・高信頼性アプリケーション向け http://www.taiwansemi.com/ja/1200v-wide-bandgap-sic-schottky-diodes/ http://www.taiwansemi.com/ja/1200v-wide-bandgap-sic-schottky-diodes/#respond Wed, 30 Jul 2025 01:00:10 +0000 https://web.ts.com.tw/ja/?p=15499 新製品の1200V ワイドバンドギャップ シリコンカーバイド (SiC) ショットキーダイオードは、MPS (Merged PIN Schottky) 構造を特長とし、高い順方向サージ電流耐量、低い順方向電圧降下、低リーク電流、および低静電容量により優れた性能を有しています。これらの特性は、高周波および高電圧アプリケーションにおける効率と堅牢性の向上に貢献します。 1Aおよび2Aの電流定格で小型SMBおよび薄型SOD-128パッケージで提供される、これらのダイオードは、改善された沿面距離(例:SOD-128で3.2mm、SMBで2.6mm)を確保し、より優れた電気的絶縁特性を実現しています。さらに高い電流が要求される用途には、最大40A定格のバージョンがTO-247-3Lパッケージで提供され、幅広い電力設計が必要な場面においての最適化を可能にします。 全デバイスはAEC-Q101認定済みで、最大ジャンクション温度175℃に対応し、EV急速充電、蓄電装置、産業用及び通信電源などの要求の厳しい環境で高い信頼性と熱安定性を確保します。さらに、順方向電圧は正の温度係数により熱管理が簡素化され、高信頼性が要求されるアプリケーションにおいて安定した性能を実現します。 パッケージと回路図 Key Features AEC-Q101準拠 SOD-128パッケージ:設計保証された最小沿面距離 3.2mm SMBパッケージ:設計保証された最小沿面距離 2.6mm 最大接合部温度 175°C MPS (Merged PIN Schottky) 設計 VF正の温度係数 RoHS準拠 ハロゲンフリー Applications PFC高周波整流 EV急速充電ステーション ブートストラップおよび非飽和ダイオード グリッド蓄電システム (ESS) 無停電電源装置 (UPS) 太陽光インバータシステム PVマイクロインバータ 通信整流器 Product Portfolio Scroll left

The post MPS構造採用 1200V ワイドバンドギャップ SiC ショットキーダイオード:高周波・高信頼性アプリケーション向け first appeared on Taiwan Semiconductor.

]]>

新製品の1200V ワイドバンドギャップ シリコンカーバイド (SiC) ショットキーダイオードは、MPS (Merged PIN Schottky) 構造を特長とし、高い順方向サージ電流耐量、低い順方向電圧降下、低リーク電流、および低静電容量により優れた性能を有しています。これらの特性は、高周波および高電圧アプリケーションにおける効率と堅牢性の向上に貢献します。

1Aおよび2Aの電流定格で小型SMBおよび薄型SOD-128パッケージで提供される、これらのダイオードは、改善された沿面距離(例:SOD-128で3.2mm、SMBで2.6mm)を確保し、より優れた電気的絶縁特性を実現しています。さらに高い電流が要求される用途には、最大40A定格のバージョンがTO-247-3Lパッケージで提供され、幅広い電力設計が必要な場面においての最適化を可能にします。

全デバイスはAEC-Q101認定済みで、最大ジャンクション温度175℃に対応し、EV急速充電、蓄電装置、産業用及び通信電源などの要求の厳しい環境で高い信頼性と熱安定性を確保します。さらに、順方向電圧は正の温度係数により熱管理が簡素化され、高信頼性が要求されるアプリケーションにおいて安定した性能を実現します。

パッケージと回路図

Key Features

  • AEC-Q101準拠
  • SOD-128パッケージ:設計保証された最小沿面距離 3.2mm
  • SMBパッケージ:設計保証された最小沿面距離 2.6mm
  • 最大接合部温度 175°C
  • MPS (Merged PIN Schottky) 設計
  • VF正の温度係数
  • RoHS準拠
  • ハロゲンフリー

Applications

  • PFC高周波整流
  • EV急速充電ステーション
  • ブートストラップおよび非飽和ダイオード
  • グリッド蓄電システム (ESS)
  • 無停電電源装置 (UPS)
  • 太陽光インバータシステム
  • PVマイクロインバータ
  • 通信整流器

Product Portfolio

Part NumberPackageVRRM (V)IF (A)VF @ TA= 25°CIR @TA= 25°C Typ. (μA)IR @TA= 175°C Typ. (μA)IFSM @10μs (A)QC Typ (nC)
Typ. (V)Max. (V)
TSCDFS01120G2HSOD-128120011.361.5352564.3
TSCDFS02120G2HSOD-12821.371.541546410.3
TSCDB01120G2HDO-214AA (SMB)11.361.5362564.3
TSCDB02120G2HDO-214AA (SMB)21.371.541546410.3
TSCDM05120G2HTO-252-2L51.381.5306058028
TSCDM08120G2HTO-252-2L81.381.53010067746
TSCDM10120G2HTO-252-2L101.391.53010084351
TSCDK05120G2HTO-263-2L51.381.5306058028
TSCDK08120G2HTO-263-2L81.381.53010067746
TSCDK10120G2HTO-263-2L101.391.53010092051
TSCDK15120G2HTO-263-2L151.381.530100124174
TSCDK20120G2HTO-263-2L201.381.530200132096
TSCDT05120G2HTO-220AC-2L51.381.5306058028
TSCDT08120G2HTO-220AC-2L81.381.53010067746
TSCDT10120G2HTO-220AC-2L101.391.53010096451
TSCDT15120G2HTO-220AC-2L151.381.530100120374
TSCDT20120G2HTO-220AC-2L201.381.530200136696
TSCDAH10120G2HTO-247-2L101.391.53010092051
TSCDAH15120G2HTO-247-2L151.381.530100115874
TSCDAH20120G2HTO-247-2L201.381.530200128096
TSCDAH30120G2HTO-247-2L301.41.5302001360142
TSCDAH40120G2HTO-247-2L401.421.5302001771184
TSCDH10120G2HTO-247-3L101.381.5306058028
TSCDH15120G2HTO-247-3L151.361.53010076546
TSCDH20120G2HTO-247-3L201.391.53010092051
TSCDH30120G2HTO-247-3L301.381.530100115874
TSCDH40120G2HTO-247-3L401.381.530200128096

The post MPS構造採用 1200V ワイドバンドギャップ SiC ショットキーダイオード:高周波・高信頼性アプリケーション向け first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/1200v-wide-bandgap-sic-schottky-diodes/feed/ 0
車載用単方向および双方向ESD保護ダイオード http://www.taiwansemi.com/ja/automotive-uni-bi-directional-esd-protection-diode/ http://www.taiwansemi.com/ja/automotive-uni-bi-directional-esd-protection-diode/#respond Mon, 21 Jul 2025 03:57:35 +0000 https://web.ts.com.tw/ja/?p=15433 タイワン・セミコンダクター社は、ウェアラブル機器やその他小型電子機器向けに超小型ESD保護デバイスを発表します。新製品TESDAxシリーズは、独自のクランピング技術を特長とし、信号ラインや電源ラインに対するESDおよび雷からの過電圧を抑制し保護対象製品を保護します。 今回の新製品は、ポータブル医療機器、スマートフォン、PDAなどの小型電子機器において、高感度な過電圧保護に最適な製品です。AEC-Q101認定を取得しているTESDAxシリーズは、IEC 61000-4-2 (ESD ±30kV 気中放電/接触放電)、IEC 61000-4-4 (EFT 40A)、IEC 61000-4-5 (雷サージ 5A) に対する堅牢な保護を提供します。パッケージは超小型パッケージを採用しており、基板の省スペース化に寄与します。 図1:パッケージと回路図 図2:TESDAxシリーズの代表的なアプリケーション 主な特長 AEC-Q101準拠 ESD保護性能: IEC 61000-4-2 (ESD) ±30kV (気中放電)、±30kV (接触放電) IEC 61000-4-4 (EFT) 40A (5/50ns) IEC 61000-4-5 (雷サージ) 5A (8/20us) 超小型パッケージによる基板の省スペース化に寄与 アプリケーション ポータブル医療機器 スマートフォン PDA 製品ポートフォリオ Scroll left Facebook LinkedIn Email

The post 車載用単方向および双方向ESD保護ダイオード first appeared on Taiwan Semiconductor.

]]>

タイワン・セミコンダクター社は、ウェアラブル機器やその他小型電子機器向けに超小型ESD保護デバイスを発表します。新製品TESDAxシリーズは、独自のクランピング技術を特長とし、信号ラインや電源ラインに対するESDおよび雷からの過電圧を抑制し保護対象製品を保護します。

今回の新製品は、ポータブル医療機器、スマートフォン、PDAなどの小型電子機器において、高感度な過電圧保護に最適な製品です。AEC-Q101認定を取得しているTESDAxシリーズは、IEC 61000-4-2 (ESD ±30kV 気中放電/接触放電)、IEC 61000-4-4 (EFT 40A)、IEC 61000-4-5 (雷サージ 5A) に対する堅牢な保護を提供します。パッケージは超小型パッケージを採用しており、基板の省スペース化に寄与します。

図1:パッケージと回路図
図2:TESDAxシリーズの代表的なアプリケーション

主な特長

  • AEC-Q101準拠
  • ESD保護性能:
    IEC 61000-4-2 (ESD) ±30kV (気中放電)、±30kV (接触放電)
    IEC 61000-4-4 (EFT) 40A (5/50ns)
    IEC 61000-4-5 (雷サージ) 5A (8/20us)
  • 超小型パッケージによる基板の省スペース化に寄与

アプリケーション

  • ポータブル医療機器
  • スマートフォン
  • PDA

製品ポートフォリオ

Part numberPackageConfigurationVWM (V)CJ (pF) Max.ESD robustness (IEC61000-4-2)
(kV)
IPP at tp = 8/20μs (A)
TESDA5V0U40P1Q0DFN0603-2LUni-directional540305
TESDA5V0B20P1Q0Bi-directional20
TESDA6V0U40P1Q0Uni-directional640
TESDA6V0B20P1Q0Bi-directional20
Facebook
LinkedIn
Email

The post 車載用単方向および双方向ESD保護ダイオード first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/automotive-uni-bi-directional-esd-protection-diode/feed/ 0
新しい150V&200Vトレンチショットキーダイオード、TO-277A (SMPC4.6U) パッケージで登場 http://www.taiwansemi.com/ja/150v-200v-trench-schottky-rectifiers-in-to-277a/ http://www.taiwansemi.com/ja/150v-200v-trench-schottky-rectifiers-in-to-277a/#respond Wed, 09 Jul 2025 01:42:48 +0000 https://web.ts.com.tw/ja/?p=15387 Taiwan Semiconductorは、新しい150Vおよび200VトレンチショットキーダイオードをTO-277A (SMPC4.6U) パッケージで発表します。これらのダイオードは、 0.78Vからの低い順方向電圧と3Aから15Aまでの順方向電流を特長とし、AEC-Q101認証を取得しています。 これらダイオードは、SMPS(スイッチング電源)の二次側整流、昇圧PFC回路、車載および通信システムにおけるフリーホイーリングダイオード、極性保護などのアプリケーションに最適です。低い順方向電圧と高い電流容量により、優れた性能を保証し、要求の厳しいお客様のアプリケーション向けに、小型で信頼性が高く、エネルギー効率の高い設計を可能にします。 主な特長: AEC-Q101準拠 最大接合部温度: 150°C 高電流定格: 3A~15A 低順方向電圧 吸湿耐性レベル: J-STD-020 レベル1 RoHS準拠 ハロゲンフリー アプリケーション: スイッチング電源 (SMPS) の12V~48V範囲の二次側出力整流 昇圧PFC回路 車載、通信、DC-DCコンバータにおけるフリーホイーリングダイオード 極性保護ダイオード 製品ポートフォリオ Scroll left

The post 新しい150V&200Vトレンチショットキーダイオード、TO-277A (SMPC4.6U) パッケージで登場 first appeared on Taiwan Semiconductor.

]]>

Taiwan Semiconductorは、新しい150Vおよび200VトレンチショットキーダイオードをTO-277A (SMPC4.6U) パッケージで発表します。これらのダイオードは、 0.78Vからの低い順方向電圧と3Aから15Aまでの順方向電流を特長とし、AEC-Q101認証を取得しています。

これらダイオードは、SMPS(スイッチング電源)の二次側整流、昇圧PFC回路、車載および通信システムにおけるフリーホイーリングダイオード、極性保護などのアプリケーションに最適です。低い順方向電圧と高い電流容量により、優れた性能を保証し、要求の厳しいお客様のアプリケーション向けに、小型で信頼性が高く、エネルギー効率の高い設計を可能にします。

主な特長:

  • AEC-Q101準拠
  • 最大接合部温度: 150°C
  • 高電流定格: 3A~15A
  • 低順方向電圧
  • 吸湿耐性レベル: J-STD-020 レベル1
  • RoHS準拠
  • ハロゲンフリー

アプリケーション:

  • スイッチング電源 (SMPS) の12V~48V範囲の二次側出力整流
  • 昇圧PFC回路
  • 車載、通信、DC-DCコンバータにおけるフリーホイーリングダイオード
  • 極性保護ダイオード

製品ポートフォリオ

Part NumberPackageVRRM (V)IF (A)VF @TA=25°CIR @ TA= 25°C Max. (μA)IR @ TA= 125°C Max. (mA)IFSM @ 8.3 ms (A)CJ (pF)
Typ. (V)Max. (V)
TSUP3150HTO-277A (SMPC4.6U)15030.780.8510580140
TSUP5150H50.780.85105125248
TSUP8150H80.780.85105200395
TSUP10150H100.80.86105200395
TSUP12150H120.780.85205285520
TSUP15150H150.760.82306400840
TSUP8200H20080.820.88105200332
TSUP10200H100.850.9105200332
TSUP12200H120.830.89205285446
TSUP15200H150.80.86306400782

The post 新しい150V&200Vトレンチショットキーダイオード、TO-277A (SMPC4.6U) パッケージで登場 first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/150v-200v-trench-schottky-rectifiers-in-to-277a/feed/ 0
AEC-Q101準拠 車載用小信号デバイスの提供開始 http://www.taiwansemi.com/ja/automotive-aec-q101-qualified-small-signal-product/ http://www.taiwansemi.com/ja/automotive-aec-q101-qualified-small-signal-product/#respond Mon, 23 Jun 2025 01:21:17 +0000 https://web.ts.com.tw/ja/?p=15325 Taiwan Semiconductorは、AEC-Q101に準拠した小信号デバイスとしてショットキーバリアダイオード、スイッチングダイオード、ツェナーダイオード、トランジスタの提供を開始します。小信号ダイオードは、その高速スイッチング特性と小型パッケージの特長から車載電子機器で広く使用されています。また、逆極性保護やより効率的な信号スイッチングを可能にし、ADASやインフォテインメントのような高感度システムにおける電圧クランプに役立ちます。また、低VF特性を有していることから高性能な車載アプリケーションに最適です。 主な特長 AEC-Q101準拠 IATF 16949認定施設で製造 吸湿耐性レベル: J-STD-020 レベル1 RoHS準拠 ハロゲンフリー アプリケーション スイッチング回路 逆極性保護 電圧レギュレータ回路 デジタル関連機器 ADAS 車載インフォテインメント ショットキーバリアダイオードの製品ポートフォリオ Scroll left * Typical value スイッチングダイオードの製品ポートフォリオ Scroll left ツェナーダイオードの製品ポートフォリオ Scroll left トランジスタの製品ポートフォリオ Scroll left Facebook LinkedIn Email

The post AEC-Q101準拠 車載用小信号デバイスの提供開始 first appeared on Taiwan Semiconductor.

]]>

Taiwan Semiconductorは、AEC-Q101に準拠した小信号デバイスとしてショットキーバリアダイオード、スイッチングダイオード、ツェナーダイオード、トランジスタの提供を開始します。小信号ダイオードは、その高速スイッチング特性と小型パッケージの特長から車載電子機器で広く使用されています。また、逆極性保護やより効率的な信号スイッチングを可能にし、ADASやインフォテインメントのような高感度システムにおける電圧クランプに役立ちます。また、低VF特性を有していることから高性能な車載アプリケーションに最適です。

主な特長

  • AEC-Q101準拠
  • IATF 16949認定施設で製造
  • 吸湿耐性レベル: J-STD-020 レベル1
  • RoHS準拠
  • ハロゲンフリー

アプリケーション

  • スイッチング回路
  • 逆極性保護
  • 電圧レギュレータ回路
  • デジタル関連機器
  • ADAS
  • 車載インフォテインメント

ショットキーバリアダイオードの製品ポートフォリオ

Part NumberPackageVR (V)IR (μA)IF Max. (mA)VF max. (V)trr max. (ns)
BAT54HSOT-233022000.85
BAT54WHSOT-3233022000.85
BAT54SHSOT-233022000.85
BAT54SWHSOT-3233022000.85
BAT54AHSOT-233022000.85
BAT54CHSOT-233022000.85
BAT54CWHSOT-3233022000.85
BAT42WSHSOD-323300.520015
BAT43WSHSOD-323300.520015
RB500V-40HSOD-3234011000.45-
BAT54GWHSOD-1233022000.85
SD103AWHSOD-1234053500.610 *
SD103BWHSOD-1233053500.610 *
SD103CWHSOD-1232053500.610 *

* Typical value

スイッチングダイオードの製品ポートフォリオ

Part NumberPackageVRRM (V)IR (μA)IF Max. (mA)VF Max. (V)trr max. (ns)
BAS16HSOT-231000.52151.254
BAS21HSOT-232500.12001.2550
BAV21WHSOD-1232500.12001.2550
BAW56WHSOT-3231000.51501.254
BAV70WHSOT-3231000.52151.254
BAV99WHSOT-3231000.51501.254
BAV70HSOT-231000.52151.254
BAV99HSOT-231000.52151.254
BAW56HSOT-231000.52151.254
1N4148WTHSOD-523F1000.51501.254
1N4148WHSOD-1231000.51501.254
1N4148WSHSOD-3231000.51501.254
BAV23CHSOT-232500.12251.2550
BAV23SHSOT-232500.12251.2550

ツェナーダイオードの製品ポートフォリオ

Part NumberPackageTolerancePD (mW)VZ (V)IZ Max. (mA)
BZX585BxxxH SeriesSOD-523F2%2002.4V~24V5
27V~51V2
BZT52BxxxSH seriesSOD-3232%2002.4V~24V5
27V~75V2
BZX84CxxxH SeriesSOT-235%3002.4V~24V5
27V~39V2
MMSZ52xxxBH seriesSOD-1235%5002.4V~12V20
13V~75V<9.5
BZX84JBxxxH seriesSOD-323F2%5502.4V~24V5
27V~75V2

トランジスタの製品ポートフォリオ

Part NumberPackagePolarityVCBO (V)VCEO (V)IC (mA)hFE
BC817-25HSOT-23NPN5045500160~400
BC817-25WHSOT-3235045500160~400
BC817-40HSOT-235045500250~600
BC817-40WHSOT-3235045500250~600
BC846BHSOT-238065100200/290/450
BC846BSHSOT-3638065100200/290/450
BC846BWHSOT-3238065100200/290/450
BC847BHSOT-235045100200/290/450
BC847BWHSOT-3235045100200/290/450
BC847CHSOT-235045100420/520/800
BC847CWHSOT-3235045100420/520/800
BC847SHSOT-3635045100110~630
MMBT2222AHSOT-237540600100~300
MMBT3904HSOT-236040200100~300
BC807-25HSOT-23PNP-50-45-500160~400
BC807-25WHSOT-323-50-45-500160~400
BC807-40HSOT-23-50-45-500250~600
BC807-40WHSOT-323-50-45-500250~600
BC856BHSOT-23-80-65-100220~475
BC856BSHSOT-363-80-65-100220~475
BC856BWHSOT-323-80-65-100220~475
BC857BHSOT-23-50-45-100220~475
BC857CHSOT-23-50-45-100420~800
BC857SHSOT-363-50-45-200125~630
BC857WHSOT-323-50-45-100125~800
MMBT2907AHSOT-23-60-60-600100~300
MMBT3906HSOT-23-40-40-200100~300
Facebook
LinkedIn
Email

The post AEC-Q101準拠 車載用小信号デバイスの提供開始 first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/automotive-aec-q101-qualified-small-signal-product/feed/ 0
1200V & 1600V High Efficiency Rectifier Extends High Voltage to Automotive Surface Mounted Package http://www.taiwansemi.com/ja/1200v-high-efficiency-rectifier-extends-high-voltage-to-automotive-surface-mounted-package/ http://www.taiwansemi.com/ja/1200v-high-efficiency-rectifier-extends-high-voltage-to-automotive-surface-mounted-package/#respond Tue, 03 Jun 2025 01:00:39 +0000 https://web.ts.com.tw/ja/?p=14647 Taiwan Semiconductor,  (TSC), a global supplier of discrete power electronics devices, LED drivers, analog ICs and ESD protection devices, announces additional 1200V & 1600V High Efficiency rectifiers in industry standard packages. The parts are targeted for bootstrap and de-saturate applications for IGBT or MOSFET gate drivers in high voltage battery systems of EVs.  Additional applications …

1200V & 1600V High Efficiency Rectifier Extends High Voltage to Automotive Surface Mounted Package Read More »

The post 1200V & 1600V High Efficiency Rectifier Extends High Voltage to Automotive Surface Mounted Package first appeared on Taiwan Semiconductor.

]]>

Taiwan Semiconductor,  (TSC), a global supplier of discrete power electronics devices, LED drivers, analog ICs and ESD protection devices, announces additional 1200V & 1600V High Efficiency rectifiers in industry standard packages.

The parts are targeted for bootstrap and de-saturate applications for IGBT or MOSFET gate drivers in high voltage battery systems of EVs.  Additional applications include alternative energy systems, metering, lighting and rectification in HV power systems.

Key Features

  • Low CJ
  • Fast trr -75ns max
  • Environmental compliance
  • TJ 175℃ max.
  • Industry standard packages

Applications

  • Bootstrapping
  • De-saturate
  • Snubber – clamping
  • Freewheeling
  • HV rectification
  • Protection – HV blocking diode

Product Portfolio

Part NumberPackageVRRM (V)IF (A)VF Max. (V)trr Max.(ns)IFSM (A)TJ Max (°C)
HS1QSMA120011.97535175
HS1QHSMA120011.97535175
HS1QBSMB120011.97535175
HS1QBHSMB120011.97535175
SOD-128120011.97535175
SOD-128120011.97535175
Thin SMA120011.97535175
Thin SMA120011.97535175
HS1YNEW
SMA160013.67530150
SMA160013.67530150
SMB160013.67530150
SMB160013.67530150

The post 1200V & 1600V High Efficiency Rectifier Extends High Voltage to Automotive Surface Mounted Package first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/1200v-high-efficiency-rectifier-extends-high-voltage-to-automotive-surface-mounted-package/feed/ 0
Automotive Bi-directional ESD Protection Diode in SOT-23 package http://www.taiwansemi.com/ja/automotive-bi-directional-esd-protection-diode-sot23/ http://www.taiwansemi.com/ja/automotive-bi-directional-esd-protection-diode-sot23/#respond Fri, 11 Apr 2025 06:38:47 +0000 https://web.ts.com.tw/ja/?p=15232 The TESDA24VB28P2CX is Bidirectional ESD-rated clamping cell to protect power interfaces, control line, or low speed data line in an electronic system. The capacitance CJ must be less than 100 pF to maintain signal integrity at the maximum data rate of 20 kbit/s. To minimize the total impact of the diode on the system, CJ …

Automotive Bi-directional ESD Protection Diode in SOT-23 package Read More »

The post Automotive Bi-directional ESD Protection Diode in SOT-23 package first appeared on Taiwan Semiconductor.

]]>

The TESDA24VB28P2CX is Bidirectional ESD-rated clamping cell to protect power interfaces, control line, or low speed data line in an electronic system. The capacitance CJ must be less than 100 pF to maintain signal integrity at the maximum data rate of 20 kbit/s. To minimize the total impact of the diode on the system, CJ should be smaller than 30 pF.  It has been specifically designed to protect sensitive electronic components connected to power and control lines from over-voltage damage caused by Electrostatic Discharging (ESD) and Lightning.

Figure 1: Package and circuit diagram

Key Features

  • AEC-Q101 qualified
  • ESD protection for 2 lines with bidirectional
    IEC61000-4-2 (ESD): ±30kV (air), ±30kV(contact)
    IEC61000-4-5 (Lightning): 5A (8/20μs)
  • Suitable for 24V and below operating voltage
  • Protect I/O line or power line

Applications

  • In-vehicle network lines
  • Industrial control systems
  • CAN bus
  • HVAC systems
Figure 2: ESD protection of two automotive CAN bus lines for typical application

Product Portfolio

Part NumberPackageVWMCJ maxESD robustness (IEC61000-4-2)IPPM (at tp= 8/20μs)
TESDA24VB28P2CXSOT-2324V28pF30KV5A
Facebook
LinkedIn
Email

The post Automotive Bi-directional ESD Protection Diode in SOT-23 package first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/automotive-bi-directional-esd-protection-diode-sot23/feed/ 0
2025 electronica http://www.taiwansemi.com/ja/2025-electronica/ http://www.taiwansemi.com/ja/2025-electronica/#respond Wed, 02 Apr 2025 03:35:12 +0000 https://web.ts.com.tw/ja/?p=15208 Dear Customers and Partners, We cordially invite you to attend Electronica China 2025 in Shanghai and visit the TSC Taiwan Semiconductor booth to explore the latest technologies and innovative applications in the electronics industry with us. Exhibition Information: Date: April 15, 2025 – April 17, 2025 Location: Shanghai New International Expo Center (SNIEC) Booth Number: …

2025 electronica Read More »

The post 2025 electronica first appeared on Taiwan Semiconductor.

]]>

Dear Customers and Partners, We cordially invite you to attend Electronica China 2025 in Shanghai and visit the TSC Taiwan Semiconductor booth to explore the latest technologies and innovative applications in the electronics industry with us.

Exhibition Information:

  • Date: April 15, 2025 – April 17, 2025
  • Location: Shanghai New International Expo Center (SNIEC)
  • Booth Number: N4.300



Exhibition Highlights:

  • [New Product/Technology 1] —— [SUPER CLAMP TVS Low Clamping TVS]
  • [New Product/Technology 2] —— [PerFET MOSFET PerFET Field Effect Transistor]
  • [New Product/Technology 3] —— [SIC SKY Silicon Carbide Schottky]



We look forward to in-depth exchanges with you at the exhibition and to jointly explore industry trends and market opportunities! Please contact us to schedule a meeting! WeChat Official Account: 台湾半导体TSC-瀚科

Facebook
LinkedIn
Email

The post 2025 electronica first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/2025-electronica/feed/ 0
Automotive Bi-directional ESD Protection Diode http://www.taiwansemi.com/ja/automotive-bi-directional-esd-protection-diode/ http://www.taiwansemi.com/ja/automotive-bi-directional-esd-protection-diode/#respond Mon, 31 Mar 2025 02:34:29 +0000 https://web.ts.com.tw/ja/?p=15181 Figure 1: Package and circuit diagram The TESDA24VB17P1Q1/TESDA24VB17P1M3 is designed to protect one line against system ESD Lightning pulses by clamping it to an acceptable reference. It provides bidirectional protection. The usage of the TESDA24VB17P1Q1 is in protected line, such as data line, control line, or power line. To minimize parasitic inductance in the board …

Automotive Bi-directional ESD Protection Diode Read More »

The post Automotive Bi-directional ESD Protection Diode first appeared on Taiwan Semiconductor.

]]>
Figure 1: Package and circuit diagram

The TESDA24VB17P1Q1/TESDA24VB17P1M3 is designed to protect one line against system ESD Lightning pulses by clamping it to an acceptable reference. It provides bidirectional protection.

The usage of the TESDA24VB17P1Q1 is in protected line, such as data line, control line, or power line. To minimize parasitic inductance in the board traces, all path lengths connected to the pins of TESDA24VB17P1Q1/TESDA24VB17P1M3 should be kept as short as possible.

Key Features

  • AEC-Q101 qualified
  • ESD protect for 1 line with bidirectional
  • Suitable for 24V and below operating voltage
  • Protect I/O line or power line.

Applications

  • In-vehicle network lines
  • Industrial control systems
  • CAN bus
  • HVAC systems
Figure 2: TESDA24VB17P1Q1 for typical application

Product Portfolio

Part numberPackageVWMCJ maxESD robustness (IEC61000-4-2)IPPM (at tp= 8/20μs)
TESDA24VB17P1Q1DFN1006-2LW24V17pF30KV5A
TESDA24VB17P1M3SOD-323
24V17pF30KV5A
Facebook
LinkedIn
Email

The post Automotive Bi-directional ESD Protection Diode first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/automotive-bi-directional-esd-protection-diode/feed/ 0
600V Low Loss rectifiers in SMD and bridge packaging http://www.taiwansemi.com/ja/600v-low-loss-rectifiers-in-smd-and-bridge-packaging/ http://www.taiwansemi.com/ja/600v-low-loss-rectifiers-in-smd-and-bridge-packaging/#respond Fri, 28 Mar 2025 01:00:24 +0000 https://web.ts.com.tw/ja/?p=15112 Taiwan Semiconductor  (TSC), a global supplier of discrete power electronics devices, LED drivers, analog ICs and ESD protection devices, announces 600V low loss rectification for power electronics systems. The current ranges are from 15A to 45A in Bridge configurations and 10 to 30A with ThinDPAK and D2PAK-D packages. The low Vf  reduces conduction loss to …

600V Low Loss rectifiers in SMD and bridge packaging Read More »

The post 600V Low Loss rectifiers in SMD and bridge packaging first appeared on Taiwan Semiconductor.

]]>

Taiwan Semiconductor  (TSC), a global supplier of discrete power electronics devices, LED drivers, analog ICs and ESD protection devices, announces 600V low loss rectification for power electronics systems.

The current ranges are from 15A to 45A in Bridge configurations and 10 to 30A with ThinDPAK and D2PAK-D packages. The low Vf  reduces conduction loss to increase efficiency and power density. TSC provides SPICE, thermal and 3D mechanical models on our website to simplify designs.  Target applications range from AC/DC converters in bridge, totem pole or bridgeless topologies for mains connected power electronics such as Server power, Telecom power and Charging systems.

Key Features

  • Planar technology
  • AEC-Q101 qualified
  • Low Vf for high efficiency
  • Low leakage current
  • # E-326243 UL certification for Bridge
  • TJ Max. 175℃

Applications

  • AC to DC converters
  • Totem pole topologies
  • Bridgeless topologies
  • EV and charging systems
  • Industrial power systems

Product Portfolio

Part NumberPackageConf.VRRM (V)IF (A)VF Max. (V)IFSM (A)TJ Max (°C)Automotive
PLAD10JHThinDPAKSingle600101260175Yes
PLDS20JHD2PAK-DSingle600201390175Yes
PLDS30JHD2PAK-DSingle600301450175Yes
PLAD10JThinDPAKSingle600101260175No
PLDS20JD2PAK-DSingle600201390175No
PLDS30JD2PAK-DSingle600301450175No
GBUL15JGBUQuad600150.9@7.5A280175No
GBUL25JGBUQuad600250.92@12.5A390175No
GBJL15JTS-6PQuad600150.9@7.5A280175No
GBJL25JTS-6PQuad600250.92@12.5A390175No
GBJL45JTS-6PQuad600450.95@22.5A620175No
Facebook
LinkedIn
Email

The post 600V Low Loss rectifiers in SMD and bridge packaging first appeared on Taiwan Semiconductor.

]]>
http://www.taiwansemi.com/ja/600v-low-loss-rectifiers-in-smd-and-bridge-packaging/feed/ 0
